The ACM-TGLUE0 is a credit card-sized Computer-on-Modules platform based on the 11th Generation Intel® Core™ Processor Family (formerly Tiger Lake UP3). This COM Express Type 10 board is a mini form factor (84 x 55mm) and is perfect for ultra-small embedded solutions in all industrial applications.
ACM-TGLUE0 supports up to 16GB LPDDR4x memory with in-band ECC, up to 64GB PCIe NVMe SSD, and offers two SATA 3.0 interfaces, 2.5GbE networking, DDI and eDP video outputs, as well as ten USB ports and four PCI Express x1 interfaces.
Although ACM-TGLUE0 is designed for mini size and high performance, it is also built to deliver consistent performance in tough environments, and with industrial Intel Core processors, it can operate in temperatures from 0°C to 60°C (-40 to 85°C for wide temperature version) and Storage in temperatures from -20°C to 70°C.
The 11th Gen Intel® Core™ processors deliver a balance of performance and responsiveness in a low-power platform built on Intel's third-generation 10nm process technology. The ACM-TGLUE0 had built-in 11th Gen Intel® Core™ processors and can deliver the strengths in total compute performance, advanced graphics/media/display, Intel® Deep Learning Boost (Intel® DL Boost), and Intel® Time Coordinated Computing (Intel® TCC).
ACM-TGLUE0 COM Express type 10 board can be applied to various industrial applications such as computer numerical control (CNC) machines, real-time controls, human-machine interfaces, tool applications, medical imaging and diagnostics (in applications like an ultrasound), other applications requiring high resolution, HDR output with AI capabilities, network video recorders, machine vision and inspection, programmable logic controllers and robotics. For more information about this great and new product, please contact us as soon as possible.
Major product specifications of ACM-TGLUE0
1.11thGeneration Intel® Core™ Processor Family (formerly Tiger Lake UP3)
2. Onboard LPDDR4x Memory16 GB.
3. 2.5 Gigabit Ethernet x 1
4. eDP x 1 , DDI x 1
5. High Definition Audio Interface
6. SATA3.0 x 2 , onboard PCIe SSD 64GB
7. USB 2.0 x 8, USB 3.2/2.0 x 2 (up to USB 3.2 Gen 2 support)
8. 4 x PCI-Express x 1
9. COM Express Type 10, Mini Size, 84 mm x 55 mm
For more product information and test samples, please free to contact us via https://www.acrosser.com/en/Contact/Inquiry
|
