Computer on Modules

Acrosser’s Com Express module products include ATX Carrier Board for Type 6 module, Type 7 Module, Type 10 module, AMD COM, and a small form factor COM Express.
About the COM-e board, Acrosser can offer consultation for customized carrier board design and development. Moreover, we also provide low-volume and diverse customized carrier board design, production, manufacturing, and assembly services to help customers who have specific needs for customized carrier boards.

Product
Model
CPU 
Serial 
Ethernet 
Display 
Expansion 
ACM-SM21E
Model:
ACM-SM21E
CPU:
-
Serial:
2 x RS-485, terminal block
Ethernet:
Ethernet 5-port 10/100, 1-port 1000
Display:
Display 1 x HDMI 2.0
Expansion:
2 x mPCIe slot
ACM-AM62E
Model:
ACM-AM62E
CPU:
ARM Cortex-A53
Serial:
2 x 2-Wire + 2 x 4-Wire
Ethernet:
Ethernet 2-port 10/100/1000
Display:
1 x HDMI 1.4a 1080P@60, 1 x 4 Lane LVDS
Expansion:
-
ACM-IMX8E
Model:
ACM-IMX8E
CPU:
NXP i.MX8M Plus Cortex-A53
Serial:
2 x UART, 2 x CAN bus, 3 x I²C, 1 x JTAG
Ethernet:
2 x Gigabit Ethernet
Display:
1 x HDMI 2.0a, 1 x dual channel 24-bit LVDS, 1 x MIPI-DSI 4-lane shared with second LVDS channel
Expansion:
-
ACM-EL6KE0
Model:
ACM-EL6KE0
CPU:
Intel Atom® x6000E,Pentium®, Celeron® series Processor
Serial:
2
Ethernet:
Intel i226IT 2.5GbE x 1
Display:
LVDS LCD/eDP, DDI x 1 Single Channel LVDS (18/24 bit)
Expansion:
PCIe [x1] x 4 LPC SMBus I2C
ACM-TGLUE0
Model:
ACM-TGLUE0
CPU:
Intel® 11th Core™ I Processor
Serial:
2
Ethernet:
1 x Intel I225LM GbE Lan, supports PXE Boot
Display:
-
Expansion:
4 x PCI-e 3.0 x1
ACM-ICLDE7
Model:
ACM-ICLDE7
CPU:
Xeon® D, LLC, up to 10c/20t CPU
Serial:
2
Ethernet:
1 x Intel I210AT GbE Lan, supports PXE Boot
Display:
-
Expansion:
32 x PCI-e 3.0 Lanes/4 x PCI-e 3.0 x2 Lanes
ACM-XD15B7
Model:
ACM-XD15B7
CPU:
Xeon® D1548 (8 Core, 2.0/2.6GHz, 12MB cache, TDP 45W)
Serial:
2
Ethernet:
1 x Intel I210AT GbE Lan, supports PXE Boot / 2 x 10 GbE with KR interface & NC-SI
Display:
-
Expansion:
24 x PCI-e 3.0 Lanes / 7 x PCI-e 2.0 Lanes
ACM-XE21B6
Model:
ACM-XE21B6
CPU:
Intel® Core i7- 9850HE/Xeon 2176M Processor
Serial:
2
Ethernet:
1 x Intel I210AT GbE Lan, supports PXE Boot
Display:
-
Expansion:
16 x PCI-e 3.0 Lanes / 8 x PCI-e 2.0 Lanes
