AAD-C622AX is a breakthrough Autonomous driving server and Edge AI CPU computing product that can support a maximum of 5 GPU cards.

AAD-C622AX has 6 major features and advantages:

1. Combination of high-End Server and In-Vehicle rugger computer.

2. Supreme GPU expansion + Rich I/O capacity

3. Wide Range DC Power System

4. Hot-Swappable SSD Module

5. Two types of cooling options.

6. Built-in IPMI Server Management.

Combination of high-End Server and In-Vehicle rugger computer, Acrosser AAD-C622Ax is powered by sever-grade Intel® 2nd Gen Xeon Scalable Processor (Cascade Lake) with C622 chipset and it provides up to 5 PCIe x16 slot that supports max 1000W power for NVIDIA® or AMD graphics engine to delivers real-time high-performance AI& edge computing capability when use under autonomous vehicle application.

Acrosser AAD-C622Ax also provide lockable I/O, 2 2 x M.2 MVME swappable SSD bay, 2 x 2.5" SATA-III storage bay for mass recording data storage and maintenance, 12Vdc or 24/48Vdc power input with power ignition control, Acrosser autonomous driving servers can be deployed to any environment and application.

With these features and advantages, Acrosser Autonomous Driving Controller/Servers can be deployed to any environment and application. There are six important applications perfect for Acrosser AAD-C622AX. They are :

1. Autonomous Driving Technology Development.

2. Autonomous Driving Data Collection.

3. HD Mapping.

4. Machine Vision.

5.AI Edge Computing in Harsh Environment like Vehicle, Vessel or Aircraft.

6. Military AI Learning and other use.

Generally speaking, AAD-C622AX is perfect for being Automated driving systems, vehicle controllers, vehicle servers, autonomous computers, autonomous vehicles, autonomous cars, self-driving cars, self-driving vehicles



1. Intel® C622 Cascade Lake Platform
2. Intel ® 2nd Gen Xeon Scalable Processor
3. 6 x RDIMM DDR4-2933
4. 3 x PCIe x16 Gen3 slot (x8 signal), 2 x PCIe x16 Gen3 slot (x4 signal)
5. 1,000W power board design to supports 3 NVIDIA graphics cards
6. 8 x Anti-loosening USB3.2 (13/16"-28 UN type female Connector)
7. 6 x M12 X-coded GbE LAN, 2 x M12 X-coded 10GbE LAN
8. 2 x M.2 MVME swappable SSD bay, 2 x 2.5" SATA-III internal Storage Bay,
9. 12Vdc or 24/48Vdc Power Input, Ignition Power Control





System
CPU            Intel®2nd Gen Xeon Scalable processor
Chipset lntel® C622 PCH
Memory 6 x DDR4-2933 RDIMM (up to 384GB)



Video
Video Memory

Intelgrated

Video Interface 1 x VGA DB15(By optional accessory kit)



Storage
SATA     2 x SATA III internal SSD bay
NVME 2 x NVME swappable SSD bay



I/O
Ethernet 6x GbE M12 X Code (intel i210-iT)
2 x 10GbE M12 (PCH C622)(By optional accessory kit)
USB 8 x USB 3.2 Gen1x1(5 Gbps)13/16”-28UN connector
Serial Port 2 x COM – DB9 (RS232/RS422/485)
CAN Bus By optional accessory kit
GPIO 4 in/ 4 out, DB9
Audio 3 x Audio jack
● Green: Audio out
● Blue: Remote switch
● Pink : Mic in
Mini-PCIe 1 x Mini PCIe socket (for WiFi)
1 x M.2 socket (for 4G/5G)
Exp. PCIe slot 3 x Exp. PCIe Gen3 x16 slot (x8 signal)
2 x Exp. PCIe Gen3 x16 slot (x4 signal)
SIM Card 2 x SIM card Socket



Others
WatchDog Timer 1~255 sec. software programmable(0=Disable)
Security TPM 2.0 (Infineon chipset)



Power Requirement
Power Input 12Vdc with power ignition,max,1000W
21/48Vdc with power ignition,max,1200w



Software
OS Support Ubuntu 18.04LTS.



Mechanical & Environment
Dimension AAD-C622A1 359*280*510 mm without wall mount kit
AAD-C622A2 359*200*510 mm without wall mount kit
Operating Temp. -20 ~ 60°C with GPU cards
Chassis metal chassis
Thermal Design Smart Cooling Fan
Storage Temp -40~80°C (-40~176°F)
Safety
Vibration
Shock
CE / FCC class B / E Mark / RoHS
IEC 60068-2-64, 5~500Hz, 3GRMS(CF/SSD)
IEC 60068-2-27, 50G 500m/s2 11MS



Packing List
● 1 x x AAD-C622A1/A2
● 1 x Ignition Terminal Block
● 1 x System Bracket
● 6 x M12 GbE M12 X-Coded Cable
● 1 x GPU Card Retaining Set



Optional Module List
● 8/16/32GB DDR4 2933 RDIMM
● 5G + GPS + GNSS module (100070174)(SIM8202G-M2)
● Wi-Fi +BT Module (100070170)
● 2 ports M12 X-coded 10G kit (100070177)
● 8 ports CAN FD Kit (100070180)
● 8 ports CAN 2.0B kit (100070181)
● 8 port USB card =>100070172
● 1DB15 VGA (100090084)(ADB-VGA2)

Specifications are subject to change without notice.



AAD-C622A1



AAD-C622A2
