The AND-APL1E1/E2 is a new ultra-compact network box with a 155 x 92 x 32 mm tiny size dimension. It is powered by Intel® N3350 SoC and designed to be easy to deploy in home offices, small businesses, and branch offices as well.

Even AND-APL1E1/E2 is such a small network box, Acorsser still designs it as a durable, reliable network appliance. It is definitely a good choice for budget buyers and ideal for deployment as a VPN, Firewall, SD-WAN, NAC, vCPE in any environment with a limited budget.

1. Intel® Apollo Lake Ce leron N3350, Atom E3940
2. On board 2GB LPDDR4 memory, Optional 1x SO-DIMM slot
3. 4 x GbE, 2 x USB 3.2 Gen1
4. 1 x Mini PCIe Expansion
5. 1 x 2.5" SATA 3 bay, On board 8GB eMMC



 CPU 1. Intel® Atom®E3940 Quad-core,
clock speed 1.6GHz
2. Intel® Celeron® N3350, Dual-core,
clock speed 2.41GHz
 Memory On board 2GB LPDDR4 memory.
Optional 1x DDR3L SO-DIMM slot, Max. 8GB(for E3940)
 WatchDog Timer Software programmable 1~255 sec.

Integrated graphics support for processors
with Intel Graphics Technology

 Chipset 4 x Intel® i 211
 Connector  4 x GbE RJ-45 with LED
 LAN bypass 1 pair Bypass (for N3350)

 SATA 1 x SATAIII port
 EMMC On board 8GB eMMC
 HDD Bay 1 x 2.5” HDD Bay

 Expansion 1 x Mini PCIe socket with SIM socket (for E3940)
 Console Port 1 x Console (1 x RJ45)
 USB 2 x USB 3.2 Gen1
 Antenna Hole Optional 2 x SMA for Wi-Fi (or 4G) (for E3940)

 Power Requirement
 Power Input DC in 12V / Adapter

 OS Support Linux Kernel 4.1.27

 Mechanical & Environment
 Dimension 165 x 92 x 40 mm
 Operating Temp. 0~40°C
 Storage temp -20~80°C

 Packing List
 ● 1 x AND-APL1Ex system
 ● 1 x SATA Cable
 ● 1 x SATA Power Cable
 ● 1 x Power Adaptor
 ● 1 x Power Cord (Option for USA/UK/EU/JPN/AU/RSA)

 Ordering Information

Intel Celeron N3350 Dual Core SoC
4x GbE, 1 pair LAN Bypass
2x USB 3.2 Gen1,
1x SATA3,


Intel Atom E3940 Quad Core SoC
4x GbE,
2x USB 3.2 Gen1,
1x SATA3, 1x mPCIe for WiFi or 4G

Specifications are subject to change without notice.
