The ACM-XD15B7, Intel Xeon D COM Express Basic Type 7 Module., is a small form factor embedded computer designed for industrial and commercial applications. It is built around the COM Express Type 7 module, which features a Xeon® D1548 2.0/2.6GHz 12MB(8 core) processor, up to 32GB of DDR4 ECC SODIMM memory, and multiple high-speed I/O interfaces. The ACM-XD15B7 supports Gigabit Ethernet, USB 3.0, USB 2.0 and 8-bit Digital I/O, 4-bit DI, and 4-bit DO, making it suitable for a wide range of applications such as digital signage, kiosks, and industrial automation. The computer is ruggedized for use in harsh environments and features a wide operating temperature range of 0°C to 60°C. The ACM-XD15B7 offers a compact and versatile solution for embedded computing needs.
| Acrosser Academy |
|
What is COM Express Type 7 module? COM Express Basic Type 7 Module is a computer-on-module (COM) specification designed for high-performance embedded computing applications. It specifies the form factor, electrical interfaces, and mounting options for a module that contains a server-class processor, memory, and high-speed I/O interfaces. The Type 7 specification defines a board size of 125mm x 95mm, making it one of the largest form factors in the COM Express family. It supports a range of high-end processors, such as Intel Xeon and Atom C3000 series, and provides multiple 10GbE interfaces, up to 32 PCIe lanes, and up to 4 memory channels. The Type 7 module is typically used in applications that require high computing and networking performance, such as data center appliances, network security appliances, and edge computing devices. Its modular architecture allows for easy upgrade and maintenance of the system. |
   3.gif) |
1. Newest platform and highest performance COM Express Basic Type 7
2. The Intel Xeon D Processor
3. Xeon® D1548 2.0/2.6GHz 12MB(8 core)
4. Support Two DDR4 ECC SODIMM , up to 32GB
5. 32 PCI-e Lanes
6. 2 x 10 GbE KR & NC-SI
| System |
| CPU | Xeon® D1548 (8 Core, 2.0/2.6GHz, 12MB cache, TDP 45W) |
| Chipset | Integrated in SoC processor |
| Memory | 2 x 2400 DDR4 SODIMM(Support ECC function) up to 32GB Default configuration: 2 x 8GB |
| BIOS | AMI |
| WatchDog Timer | Software programmable 1~255 sec |
| Storage |
| SATA | ● 2 x SATA III with 6Gb/s |
| I/O |
| Ethernet Chip | ● Intel I210AT GbE Lan, supports PXE Boot ● 2 x 10 GbE with KR interface & NC-SI |
| Expansion Interface | ● 24 x PCI-e 3.0 Lanes ● 7 x PCI-e 2.0 Lanes |
| Serial Interface | 2 x COM port Interface (TX/RX only) |
| USB | 4 x USB 3.0, 8 x USB 2.0 |
| GPIO | 8-bit Digital I/O, 4-bit DI and 4-bit DO |
| Audio Codec | Intel HD Audio Channel |
| Software |
| OS Support | ● Linux Kernel 4.9 & above |
| Power Requirement |
| Power Input | ● 1 x 24-pin ATX Power Connector ● 1 x 8-pin ATX 12V Power Connector |
| Power Consumption | TBD |
| Mechanical & Environment |
| Dimension | 125 mm x 95 mm (4.92" x 3.74") COM Express Basic |
| Weight | TBD |
| Operating Temp. | 0~60°C (-4~140°F) |
| Storage Temp. | -20~80°C (-4~176°F) |
| Relative Humidity | 0~90% @, non-condensing |
| Safety | CE, FCC Compliant |
| Packing List |
| ● 1 x ACM-XD15MT |
| ● 1 x CD Title |
| ● 1 x Quick Guide |
| Ordering Information |
| ACM-XD15B7 | Intel Xeon D 1548 , COM Express Basic Type 7 Module |
Specifications are subject to change without notice.
